MAXFILTERBRD
Evaluates: MAX7408–MAX7415/
MAX7418–MAX7425
General Description
The MAXFILTERBRD is an unpopulated PCB design to
evaluate the MAX7408–MAX7415/MAX7418–MAX7425
5th-order, lowpass, switched-capacitor filters (SCFs).
Contact the factory for free samples of the pin-compat-
ible MAX7408–MAX7415/MAX7418–MAX7425 SCFs to
evaluate these devices.
Features
S CLK Pad for External Clock Frequency
S Lead(Pb)-Free and RoHS Compliant
S Proven PCB Layout
Ordering Information
PART
MAXFILTERBRD+
+ Denotes lead(Pb)-free and RoHS compliant.
TYPE
EV Kit
FILTER TYPE
PART
Part Selection Table
OPERATING
VOLTAGE
DESIGNATION
Component List
(Suggested Components)
QTY DESCRIPTION
MAX7408CUA+
5V
Elliptic
Not installed, 47pF Q 5%, 50V
MAX7409CUA+
MAX7410CUA+
MAX7411CUA+
MAX7412CUA+
MAX7413CUA+
MAX7414CUA+
MAX7415CUA+
MAX7418CUA+
MAX7419CUA+
MAX7420CUA+
MAX7421CUA+
MAX7422CUA+
MAX7423CUA+
MAX7424CUA+
5V
5V
5V
3V
3V
3V
3V
5V
5V
5V
5V
3V
3V
3V
Bessel
Butterworth
Elliptic
Elliptic
Bessel
Butterworth
Elliptic
Elliptic
Bessel
Butterworth
Elliptic
Elliptic
Bessel
Butterworth
C1
C2
C3, C4
JU1, JU2
R1
0
0
0
0
0
C0G ceramic capacitor (0805)
Murata GRM2165C1H470J or
similar
Not installed, 2200pF Q 5%, 50V
C0G ceramic capacitor (0805)
Murata GRM2165C1H222J or
similar
Not installed, 0.1 F F Q 10%, 16V
X7R ceramic capacitors (0603)
Murata GCM188R71C104K or
similar
Not installed, 2-pin headers—
shorted by PC trace
Not installed, 10k I Q 1% resistor
(0805)
MAX7425CUA+ 3V Elliptic
Note: Contact the factory to order a free sample of any of the
SCF parts.
U1
—
0
1
Not installed, lowpass SCF
(8 F MAX M )
See the Part Selection Table
PCB: MAXFILTERBRD+
Component Supplier
SUPPLIER
Murata Electronics North America, Inc.
PHONE
770-436-1300
WEBSITE
www.murata-northamerica.com
Note: Indicate that you are using the MAXFILTERBRD when contacting this component supplier.
μMAX is a registered trademark of Maxim Integrated Products, Inc.
For pricing, delivery, and ordering information, please contact Maxim Direct
at 1-888-629-4642, or visit Maxim’s website at www.maximintegrated.com.
19-4884; Rev 0; 8/09
